Switch Cisco Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Essentials
Brand:
CISCO
- Others:Задължителен е минимум 3-годишен лиценз DNA Essentials.
- Dimensions (W, L, H), mm:445 x 288 x 44
- Switch type:Fixed Port
- Total number of ports:28
- Main ports, typ:24x10/100/1000Base-T
- Power over Ethernet (PoE):No
- Uplink ports:4x10/100/1000Base-T
- Free (10GB) slots:No
- Stackable:Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)
- Fans_TEXT:Fixed redundant
- Fans:Yes
- Routing:Layer 3 Advanced
- Memory (Flash, RAM):Flash memory: 4 GB; RAM: 2 GB DRAM
- Routing/switching capacity, Gbps:56 Gbps
- Throughput, Mpps:83.33 Mpps
- MAC addresses:16000 MAC address
- VLAN (number, standards):VLAN IDs: 1024; IEEE 802.1Q VLAN
- QoS:Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per p...
- L2 network standards:IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
- L3 network standards:IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
- IPv6 functionality:IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
- Mounting option:Rackmount
- :Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-125WAC
- :SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
- :Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
