Brand:
ZYXEL
-
Dimensions (W, L, H), mm:330 x 230 x 44 mm
-
Switch type:Fixed Port, Smart Managed
-
Main ports, typ:8x 10GBase-T
-
Power over Ethernet (PoE):No
-
Uplink ports:2x 10-Gigabit SFP+
-
Free (10GB) slots:-
-
Stackable:Dual stack (RFC 4213)
-
Fans_TEXT:Smart fan design
-
Fans:Yes
-
Routing:Static route; Assigned DHCP relay with specific source IP interface
-
Memory (Flash, RAM):32 MB/256 MB (Flash/RAM)
-
Routing/switching capacity, Gbps:200 Gbps
-
Throughput, Mpps:148.8 Mpps
-
MAC addresses:16 K
-
VLAN (number, standards):802.1x VLAN and bandwidth; 802.1Q Static VLANs/Dynamic VLANs: 1K/4K; Support up to 4K VLAN ID*; Independent VLAN Learning (IVL)*; Port-based VLAN*; Voice VLAN*; VLAN trunking (* Cloud and standalone modes supported)
-
L2 network standards:IEEE 802.3ab/an/ae/af/at//bt/x/z
-
L3 network standards:MSTP, GVRP, RFC
-
IPv6 functionality:IPv6 over Ethernet (RFC 2464), IPv6 addressing architecture (RFC 4291), Dual stack (RFC 4213), ICMPv6 (RFC 4884), Path MTU (RFC 1981), Encapsulation for maximum MTU of 1500, Neighbor discovery (RFC 4861), DHCPv6 relay, DHCP, DAD
-
Mounting option:Rackmount
-
:802.1X*, Port security*, MAC authentication*, Static MAC forwarding, SSL, Static ARP, RADIUS, ACL packet filtering, Port isolation, MAC search, Guest VLAN, Policy-based security filtering and etc.
-
:No. of hardware queues per port: 8*; 802.1p queuing methods: SPQ, WRR, WFQ*; Storm control: broadcast, unknown L2MC, unknown unicast (DLF)*; Rate limiting per port; Policy-based rate limiting; Policy-based prioritization
-
:10
-
:Standalone management by Web, Cloud management by Nebula Control Center*, SNMP, RMON, Syslog, IEEE 802.1AB LLDP, DHCP, NTP Server, Management through Telnet
-
Warranty:99
